High-linearity 4-Watt power amplifier for Ka-band high-data-density SATCOM offered by M/A-COM

Feb. 2, 2015
LOWELL, Mass., 2 Feb. 2015. M/A-COM Technology Solutions Inc. in Lowell, Mass., is introducing the MAAP-011139 high-linearity 4-Watt power amplifier for Ka-band high-data-density satellite communications (SATCOM).

LOWELL, Mass., 2 Feb. 2015. M/A-COM Technology Solutions Inc. in Lowell, Mass., is introducing the MAAP-011139 high-linearity 4-Watt power amplifier for Ka-band high-data-density satellite communications (SATCOM).

M/A-COM's MAAP-011139 RF and microwave device comes in bare die format and a 5-by-5-millimeter 32-lead QFN package. The device delivers 24 dB of linear gain, 4-Watts of saturated output power, and 23 percent efficiency.

The device provides greater than 27 dBm Pout/tone while maintaining IM3 levels of 30 dBc, which enables the MAAP-011139 to replace two equivalent competing alternatives with one device while operating in an overall more efficient mode, company officials say.

Related: GaAs MMIC amplifier for X-band communications and radar introduced by M/A-COM

The device in bare die format and measures 3.1 by 2.8 by-0.05 millimeters for space-constrained applications.

For more information contact M/A-COM online at www.macom.com.
