Researchers consider 3D chip optical interconnects to boost efficiency and speed information throughput

Aug. 7, 2024
The program will seek hardware demonstrations of low-loss, high-density optical interconnects that are compatible with microelectronics.

ARLINGTON, Va. – U.S. military researchers are ready to kick-off a project to develop 3D chip-to-chip and intra-chip optical routing to speed information throughput and reduce vulnerability to electromagnetic interference.

Officials of the U.S. Defense Advanced Research Projects Agency (DARPA) in Arlington, Va., issued a special notice last week (DARPA-SN-24-90) for the upcoming Heterogenous Adaptively Produced Photonic Interfaces (HAPPI) program.

The program will seek hardware demonstrations of low-loss, high-density optical interconnects using a scalable manufacturing process that is compatible with microelectronics.

The HAPPI program focuses on high-density 3D chip optical links and the ability to provide several routing planes within a photonic integrated circuit or photonic interposer.

Related: The future of high-performance embedded computing

The project also will emphasize vertical connections between routing layers that can traverse substrate thickness, and surface methods for coupling light from one photonic chip to another. Chip-to-fiber coupling and chip-to-chip edge coupling are not part of the program.

A major thrust of the program is to create optical interfaces that are robust to typical microsystem misalignments due to fabrication and assembly variability, especially for large link arrays that span reticle-or wafer-scale systems.

The program also will seek robust-by-design or adaptive interfaces capable of environmentally and mechanically stable optical performance, with compatibility with standard microelectronics manufacturing and assembly flows.

Related: DARPA researchers to brief industry in June on microelectronics for photonic circuits and quantum computing

Approaches should include coupling to a photonic integrated circuit with demonstrated optoelectronic sources, amplifiers, modulators, multiplexers, filters, detectors, and other electro-optical components. The operating wavelengths may be within the visible or near infrared optical bands.

Companies interested my ask by email to be added to an email distribution list for future program updates to Anna Tauke Pedretti at [email protected].

Announcements of industry briefings and broad agency announcements will come later. Email questions or concerns to DARPA's Anna Tauke Pedretti at [email protected]. More information is online at https://sam.gov/opp/de806aaf9561482ba0e2c18f64c5f0f3/view.
