Solenoids for power electronics and motion control in cabinet locks introduced by Magnetic Sensor Systems
VAN NUYS, Calif. – Magnetic Sensor Systems (MSS) in Van Nuys, Calif., is introducing the S-20-100X model of pull-type tabular solenoids for valve control, door controls, cabinet locks, disconnects, transmission shifting, fire suppression systems, medical dispensing, mixing, and sorting equipment.
The S-20-100X series of power electronics devices features 18 different solenoids based on voltage, duty cycle, force, and stroke. MSS Solenoids coils typically use class F 23-to-40 American Wire Gauge (AWG) windings with class A insulation to protect the solenoid during long duty cycles.
The S-20-100X solenoids for motion control applications feature a 1-inch-diameter by 2-inch-long housing and a 3/4 -16 UNF-2A thread for mounting. The noncaptive plunger or actuator has a diameter of 0.437 inches with a clevis end for load attachment. A low-friction brass guide and PTFE coating on the plunger assures long life.
These clean, high efficiency, low cost, precise tubular solenoids can operate at 1/10, 1/4, 1/2, and continuous-duty voltage-dependent cycles.
For more information contact Magnetic Sensor Systems online at www.magneticsensorsystems.com.
