Oscilloscopes for optical networking testing and development introduced by Keysight
SANTA ROSA, Calif. – Keysight Technologies Inc. in Santa Rosa, Calif., is introducing the Infiniium UXR-series of oscilloscopes for high-speed serial and optical networking test, measurement, and development.
These models range from 13 to 110 GHz of analog bandwidth to enable designers create designs in any generation of DDR, USB, PCIe or other serial technologies, as well as PAM4, 5G, radar, satellite communications, and optical designs.
These oscilloscopes deliver a low noise floor and high vertical resolution to ensure measurements. Keysight Infiniium UXR-series 13 to 110 GHz oscilloscope models enable designers to accelerate time to market of their innovation, with:
-- 10-bit vertical resolution and signal integrity for superior effective number of bits (ENOB), leading to faster compliance test and measurement (link to topic center) testing with higher margins;
-- sampling rates of 256 gigasamples per second per channel on 40 to 110 GHz models and 128 gigasamples per second per channel on 13 to 33 GHz models;
-- as many as four full-bandwidth channels with less than 35 fs (rms) of inter-channel intrinsic jitter providing accurate timing and skew measurements;
-- an optional factory grade self-calibration module which ensures ongoing measurement accuracy while reducing the need to take the unit out of service; and
-- a chipset based on a Keysight-proprietary indium phosphide (InP) process that enables exceptionally wide bandwidth and extremely low noise floor for optical networking test and measurement.
Related: Signal analyzer for test and measurement at millimeter-wave frequencies offered by Keysight
Keysight also announced two additional solutions that, when paired with the company's Infiniium UXR-series oscilloscopes, offer a end-to-end solution from stimulus to analysis for PAM4 and 400G, 600G, as well as terabit coherent optical interconnect designs. These solutions include:
-- N4391B Optical Modulation Analyzer (OMA) -- a compact, real-time oscilloscope-based OMA designed specifically for complex optical data transmission and terabit measurement challenges; and
-- M8194A 120 gigasamples per second arbitrary waveform generator (AWG) -- Keysight's fastest AWG delivers a level of stimulus performance for generating challenging formats such as 64 gigabaud 64QAM (quadrature amplitude modulation) and other wideband modulation schemes.
For more information contact Keysight online at www.keysight.com.
