Advanced Acoustic Concepts to provide submarine torpedo sonar signal transmitters and warhead electronics
NEWPORT, R.I. – U.S. Navy undersea warfare experts needed electronic components for the Navy MK 48 heavyweight torpedo for a variety of U.S. and allied submarines. They found a solution from Advanced Acoustic Concepts LLC in Washington.
Officials of the Naval Undersea Warfare Center Division Newport in Newport, R.I., announced a $21.2 million contract to Advanced Acoustic Concepts in late February for MK 48 sonar signal transmitters, warhead electronic system assemblies, and test sets.
Submarine armament
The MK 48 torpedo is standard armament for the Navy's fleet of Los Angeles-, Virginia-, and Seawolf-class fast attack submarines, as well as Ohio-class ballistic- and cruise-missile submarines. The torpedo also is for Australian Collins-class attack submarines, and Taiwanese submarines. The MK 48 relies on crucial electronic components like sonar signal transmitters and warhead electronics.
The MK 48 torpedo is 19 feet long, 21 inches in diameter, and weighs 3,500 pounds. It can dive as deeply as 1,200 feet to attack enemy submarines and surface warships as far away as five miles. The torpedo can travel as fast as 28 knots and has a 650-pound high-explosive warhead.
The much-upgraded MK 48 torpedo has been in service since 1972, and is the U.S. Navy's primary submarine weapon for use against enemy submarines and surface ships.
The MK 48 and its improved Advanced Capability (ADCAP) torpedoes can be guided from a submarine by wires attached to the torpedo. They also can use their own active pinging sonar or passive listening sonar to carry out programmed target search, acquisition, and attack procedures.
Under-keel explosion
The torpedo is designed to detonate under the keel of a surface ship to break the keel and sink the ship quickly. After a miss, the torpedo can circle back for another attempt at hitting its target. The torpedo's seeker has an active electronically steered 2D phased array active sonar.
The latest version of the MK 48 is the MK 48 Mod 7 Common Broadband Advanced Sonar System (CBASS) with expanded operational capabilities for shallow waters along coastlines and inside harbors, as well as in the deep-water open ocean.
The CBASS broadband sonar enhancement makes the torpedo more effective against new enemy submarines in harsh acoustic environments. It uses modern commercial-off-the-shelf (COTS) technologies in an open-architecture computing environment, and can be improved with regular hardware and software upgrades.
The MK 48 Mod 7 CBASS kit’s evolutionary design and modular nature makes the upgrade of older version MK 48 torpedoes to the Mod 7 CBASS capability a relatively straightforward effort without requiring significant torpedo redesign and certification.
Multiband sonar
The CBASS torpedo also has the ability of multiband operation with active and passive homing; advanced counter-countermeasure capabilities; effectiveness against low-Doppler shallow submarines, fast deep diving submarines, and high-performance surface ships; autonomous fire-and-forget operation or wire-guide capability to enable post-launch monitoring and updates via the submarine combat system; and running Otto Fuel II as the propellant.
The MK 48 Mod 7 CBASS provides the ability to transmit and receive over a wide frequency band and use broadband signal processing techniques to improve the torpedo’s search, acquisition, and attack effectiveness.
Related: Radstone to supply COTS CPU boards for new torpedo
On this contract Advanced Acoustic Concepts will do the work in Lemont Furnace and Johnstown, Pa.; Reston, Va.; and Keyport, Wash., and should be finished by November 2027.
For more information contact Advanced Acoustic Concepts online at https://advancedacousticconcepts.com, or the Naval Undersea Warfare Center Division Newport at https://www.navsea.navy.mil/Home/Warfare-Centers/NUWC-Newport/.
