Oscilloscopes for high-performance test and measurement applications introduced by SIGLENT Technologies
SOLON, Ohio – SIGLENT Technologies America Inc. in Solon, Ohio, is introducing the SDS6000A series of oscilloscopes for high-performance test and measurement applications.
The SDS6000A oscilloscopes are available with a maximum bandwidth of two GHz. In addition to the higher bandwidth, the device offers five gigasamples per second per channel and an interpolation technique enhanced sample rate (ESR) for equivalent sample rates to 10 gigasamples per second per channel.
This also is the first SIGLENT oscilloscope with an A/D converter per channel to enable the scope to maintain a high sample rate, regardless of the number of channels activated.
The input stage delivers spurious-free dynamic range (SFDR) of more than 45 dBc, channel-to-channel isolation to 70 dBc, and DC amplifier accuracy plus-or-minus 1.5 percent to capture small signals at 500 microvolts per division.
Furthermore, the high resolution of these high-performance oscilloscopes improves the vertical resolution from 8 to 16 bits and enhances the signal acquisition accuracy.
The SDS6000A oscilloscopes are available in 500 MHz, 1 GHz and 2 GHz bandwidths. The acquisition memory has a maximum size of 500 Mpts and is distributed over 1, 2, or 4 channels. The waveform capture rate can reach up to 750,000 waveforms per second in sequence mode.
Together with the digital trigger and trigger types, users can isolate rare events quickly and efficiently. The zone trigger offers enhanced flexibility by delivering two user-defined zones that can be positioned individually and used in inclusive or exclusive modes.
For deep insights the acquired signals can be zoomed in the X and Y directions. The analysis can be carried out using many implemented measurement functions including a formula editor and four mathematical curves.
The history function, mask test, Bode plot and a bundle of serial bus decoders (I2C, SPI, UART, CAN, LIN) are implemented as standard in this series. The SDS6000A can optionally be expanded by 16 digital channels and an external function generator (25 MHz).
The large 12-inch 1280-by-800-pixel touchscreen offers enough space to display several signals at the same time. The shortcut menu helps with configuration and offers quick access to most important functions.
For more information contact SIGLENT online at https://siglentna.com.
