Portable, lightweight oscilloscope with benchtop test and measurement performance introduced by Tektronix

BEAVERTON, Ore. – Tektronix Inc. in Beaverton, Ore., is introducing the 2 Series portable mixed-signal oscilloscope combines optional arbitrary function generator (AFG), pattern generator, voltmeter, and frequency counter into one unit to reduce the number of instruments to carry or purchase.

The 2 Series mixed-signal oscilloscope can go from the bench to the field and back, and offers benchtop performance and the Tektronix user interface. It weighs less than four pounds, is 1.5 inches thick, and can fit into a small backpack for portability.

The easy to use 10.1-inch touchscreen display has as much as eight hours of battery power. It has the feel of a mobile device and colored LED ring lights around the knobs to indicate active sources or parameters to adjust or to indicate status.

Related: Test and measurement equipment keeps high-tech systems in working order

The 2 Series mixed-signal oscilloscope includes bandwidths from 70 MHz-500 MHz; two or four analog channel inputs; 16 digital channels (available with future software release); 2.5-gigasample-per-second sample rate; and optional 50 MHz arbitrary function generator.

Natively integrated software tools enable engineers to collaborate, troubleshoot, and debug designs across time zones.

The 2 Series mixed-signal oscilloscope includes TekDrive, a test and measurementt data workspace in the cloud where engineers can upload, store, organize, and share any file from a connected device. Users also can perform analysis on a waveform and save it back to the cloud for viewing and feedback from peers.

For more information contact Tektronix online at www.tek.com/2-series-mso.
