Series of hands-free oscilloscope probes for test and measurement of sensitive circuits offered by Saelig
FAIRPORT, N.Y. – Electronics distributor Saelig Co. Inc. in Fairport, N.Y. is offering the SQG-series of passive high-frequency hands-free oscilloscope probes from Sensepeek AB in Vellinge, Sweden, for AC and DC GHz test and measurement applications.
When used with Sensepeek baseplates or handheld, this series enables engineers to perform measurements at frequencies as high as 6 GHz without the need to solder connections to the test printed circuit board.
The SQG-series has low probe-tip capacitance, which minimizes loading and signal distortion for sensitive circuits. The probes, which offer a flat frequency response over a wide frequency range, make measuring high-rate data signals economical and precise. The series is available as AC or DC-coupled probes.
Six probes in series
The six members of the Sensepeek SQC 10:1 passive probe series are: 1.5 GHz: SQG15-AC / SQG15-DC - 1.5 GHz; 3 GHz: SQG30-AC / SQG30-DC; 6 GHz: SQG60-AC / SQG60-DC. The SQG-series is suitable for use with any 50 ohm input measurement instrument, including: oscilloscopes, spectrum and network analyzers, receivers, and power meters.
The SQG-series includes exchangeable fine-pitch spring-tipped test and measurement needles, ensuring reliable contact with small or delicate components. The dual ground options, a dual needle ground with a 2.3-millimeter tip pitch for PCB-mounted RF connectors, and a solid single ground with a 6.5-millimeter tip pitch for when ground points are far away.
For more information contact Saelig online at www.saelig.com, or Sensepeek AB at https://sensepeek.com.
