High-power directional couplers for sampling, calibration, and power amplifier test beds introduced by RLC

MOUNT KISCO, N.Y. – RLC Electronics Inc. in Mount Kisco, N.Y., is introducing high-power, high-directivity directional couplers for power electronics applications in high-power sampling and signal leveling; traveling wave tube amplifier; high-power amplifier test beds; calibration labs; power monitoring; and voltage standing wave ratio measurements.

RLC offers power coupling as accurate as +/-1.0dB, insertion loss as low as 0.1 to 0.35dB max, and less than 35dB directivity in both directions. These high-power couplers come with 500 to 1000 Watts average power handling to 18 GHz, as well as 100-Watt versions to 40 GHz.

Power couplers are available in single- and dual-directional construction, typically over a 2 octave bandwidth or less. RLC can use SC or 7/16 connectors on the main line, should this be needed to meet customer designs.

For more information contact RLC Electronics online at https://rlcelectronics.com.
