BAE Systems and Qorvo to help cool GaN power amplifiers for electronic warfare (EW) and radar applications
ARLINGTON, Va. – BAE Systems and Qorvo Inc. are joining a U.S. military research project to limit waste heat in gallium nitride (GaN)-based power amplifiers that could limit the performance and lifetimes of military radar, electronic warfare (EW), communications, and other RF and microwave systems.
Officials of the U.S. Defense Advanced Research Projects Agency (DARPA) in Arlington, Va., awarded contracts this month to the BAE Systems Electronic Systems segment in Merrimack, N.H., and to Qorvo Inc. in Richardson, Texas, for the Technologies for Heat Removal in Electronics at the Device Scale (THREADS) program.
BAE Systems and Qorvo join Raytheon Technologies Corp. (RTX) and Northrop Grumman Corp. on the THREADS program to cool RF and microwave GaN components. BAE Systems on a $12.4 million THREADS contract on 17 Nov., and Qorvo won a $12.7 million THREADS contract on 28 Nov. Raytheon and Northrop Grumman won their THREADS contracts in September.
THREADS seeks to develop RF and microwave microelectronics technologies that will overcome the thermal limitations that can prevent transistors from operating reliably at RF output power density close to their fundamental electronic limits.
The performance of radar and communication systems depends on the signal-to-noise ratio achievable at the receiver, which is proportional to the RF output power of the transmitter. The size of RF apertures in military systems often are limited, so the only way to increase range is by increasing the RF output power of the transmitter power amplifier.
The RF output power densities of today’s military RF transmitters substantially are thermally limited to below their theoretical electronic limits. Wide-bandgap transistors like gallium nitride (GaN) were developed to improve output power in power amplifiers by as much as five times compared to older gallium arsenide (GaAs) transistor technology.
Yet limiting increases in sustained GaN power output continues to be excessive waste heat in the transistor channel layer, which causes elevated channel temperatures and device damage.
Achieving the transistor output power near the GaN fundamental electronic limit while maintaining a channel temperature below the nominal maximum temperature of 225 degrees Celsius requires a significant reduction in the thermal resistance of the transistor, while preserving electronic properties of wide-bandgap semiconductors.
In the THREADS program, the four companies will focus on achieving high power density by reducing transistor thermal resistance in two ways: reducing thermal resistance within the device while maintaining good channel current transport properties; and moving heat away from high-power transistors more efficiently without degrading RF performance.
The companies will demonstrate efficient X-band transistors and power amplifiers. an eight-times reduction in transistor thermal resistance; and reliable operation with a mean-time-to-failure of 106 hours at 225 C channel temperature.
Engineers will try to reduce thermal resistance within the device while maintaining good channel current transport properties by reducing interfacial and thin film thermal resistance within the device's epitaxial layer stack. THREADS also will develop new ways to spread waste heat and reduce transistor thermal resistance to maintain channel temperature of 225 C.
The companies will incorporate electro-thermal co-design, modeling, and simulation to guide device optimization. THREADS is a four-year program.
For more information contact BAE Systems Electronic Systems online at www.baesystems.com; Qorvo at www.qorvo.com; Raytheon at www.rtx.com/raytheon/what-we-do/advanced-technology/microelectronics; Northrop Grumman at www.northropgrumman.com/what-we-do/microelectronics-space-park; or DARPA at www.darpa.mil.
